Computer Hot Seller Peripheral Component Parts provide Disk Storage,Game Console,Networking Tools,computers hot seller Excellent Limited LCD controller board with VGA input signal work for 6.5inch~14inch lcd display. Price at this time US $23.28/piece. Check price now to get discount! Dont waste your time. Buy Now only in VS DISPLAY's store Trusted Seller Store!
Excellent item can boost the top quality of your life. Eligible to be acquired. Economical rate as well as free delivery. Allow's get before rates climb.
This Flash Deal Excellent Limited LCD controller board with VGA input signal work for 6.5inch~14inch lcd display product is really unique, made with quality materials definitely resilient for use in a lengthy period. Before you utilize it, make certain you check out the overview thoroughly. When using it, do not make a blunder. When using it, quality products guarantee your life much more comfortable. You can directly speak to the sales to obtain even more information about this top quality goods if you are interested to purchase it.
Notice: Please give me your LCD Panel Mode No. when you buy this item
Description:
1.VGA input 2.Power supply 3.Inverter 4.LCD Voltage Jumper 5.KeyBoard 6.LVDS interface
Please check your lcd screens operating voltage and make sure the board was set correct:
Jumper: CN9 PIN 2 PIN3 3.3V
Jumper: CN9 PIN 1 PIN2 5.0V
Jumper: CN7 PIN 1 PIN2 12.0V
| Chipset | RTD2025L |
| Panel interface | Double LVDS |
| Resolutions | 1440*900 |
| Power supply | 12V |
| Voltage to panel | +3.3V/5V/12V |
| Standby | <1W |
| Input signal | VGA |
| OSD language | Chinese/English/French/Germany/Korean…(customizable) |
| keyBoard | Power,Menu,+/-,Auto/EXIT |
Note:
Can work with below model:
| G065VN01V2 | TD141TGCB1 | LTM14C421 | |
| HT10X21-311 | LTD104EA5W | LTM09C362 | LTM13C417 |
| G104SN03 | HV121X03-100 | LTD121EX1S | LTN121XJL03 |
| HT12x12-100 | LC121S1 | LTD121EXVV | N121I3-L01 |
| HT12x13-100 | LP121X04(C2) | LTD133EXZX | QD15XL02 |
| HT12X21-100 | LP133x7(C2CC) | LTM09C362F | TM121XG-02L02 |
| HT13x21-220 | LP133x7(G2QT) | LTM12C278P | TM121XG-02L02D |
| HV121P01 | LP133X8 | LTN121X1-L01 | TS104SAALC01-00 |
| HV121P01-100 | LP133X8(A2AC) | LTN121x1-L02 | UB133X01-2 |
PS: Not included all of model ,Other model please contact us or leave a message.
Package content:
1× New VGA Controller Board B.RTMC1B-A
1× LVDS Cable DF19-20P Single 8bit(compatible with 6 bit LVDS)
1× Inverter Board(1-lamp 2-lamp or 4-lamp depend on your lcd panel)
1×Keyboard with Wire
Return Policy
If the product you receive is not as described or low quality, the seller promises that you may return it before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe) and receive a full refund. The return shipping fee will be paid by you. Or, you can choose to keep the product and agree the refund amount directly with the seller.N.B.: If the seller provides the "Longer Protection" service on this product, you may ask for refund up to 15 days after order completion.
Seller Service
On-time Delivery: If you do not receive your purchase within 60 days, you can ask for a full refund before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe).Excellent Limited LCD controller board with VGA input signal work for 6.5inch~14inch lcd display
