Computer Hot Seller Peripheral Component Parts provide Memory Cards,Networking Device,computers hot seller Big Discount VGA+DVI LCD controller board for 15inch~19inch lcd panel. Price at this time US $26.39/piece. Check price now to get discount! Dont waste your time. Buy Now only in VS DISPLAY's store Trusted Seller Store!
Notice: Please give me your LCD Panel Mode No. when you buy this item
1.KeyBoard 2.LVDS interface 3.LCD Voltage Jumper
4.Power supply 5.Inverter 6.DVI Input 7.VGA input
LCD screens operating voltage Jumper:
Jumper: CN9 PIN 2 PIN3 3.3V
Jumper: CN9 PIN 1 PIN2 5.0V
Jumper: CN7 PIN 1 PIN2 12.0V
| Chipset | NT68667(FG/HFG)/NT68667(UFG) |
| Panel interface | Double LVDS |
| Resolutions | 1680*1050((FG/HFG)/1920*1200((UFG) |
| Power supply | 5V/12V |
| Voltage to panel | +3.3V/5V/12V |
| Standby | <1W |
| Input signal | VGA+DVI |
| OSD language | Chinese/English/French/Germany/Korean…(customizable) |
| keyBoard | Power,Menu,+/-,Auto/EXIT |
Example:Work with 15.4inch B154PW02:
Note:
When you bid it, please leave a message: LCD screen Model No. We will update the suitable firmware for you.
Can work with below model:
| B150PG03_V0 | LP141WP1 | LP171WP4(TL)(B4) | LQ170M1LA2A | LTN154P3-L01 |
| B150PN01 | LP150E02(A2)(P1) | LP171WP4(TL)(B5) | LQ170M1LA3C | LTN154U1-L01 |
| B154PW01/02 | LP150E06 | LP171WP4(TL)(N2) | LQ170M1LA4B | LTN154U1-L02 |
| B154SW01 | LP150E06 (A3)(K2) | LP171WP4(TL)(R2) | LQ170M1LA4G | LTN154U2-L04 |
| B170PW01 | LP150E07 | LP171WP4-TLN1 | LTD121KM2M | LTN154U2-L06 |
| B170PW02 | LP150U03(A2)(P1) | LP171WU1 | LTD141EM6K | LTN154WU1-A1 |
| B170PW03 | LP150U1 | LP171WU1(A4)(K2) | LTD154EZ0D | LTN170CT01-001 |
| B170PW04 | LP150U1-A2 | LP171WU1(A4)(K5) | LTN106W1-L01 | LTN170U1-L01 |
| B170PW05 | LP150X08-A2 | LP171WU1(TL)(A2) | LTN141P2-L01 | LTN170WP-L02 |
| B170PW06 | LP154WP1 | LP171WU1(TL)(A5) | LTN141P4-L01 | LTN170WU-L01 |
| B170UW01 | LP154WU1 (A1) | LP171WU1(TL)(B2) | LTN141P4-L04 | LTN170WU-L02 |
| B170UW02 | LP154WU1(A1)(K2) | LP171WU1-TLA8 | LTN141WD-L01 | LTN170WX-L01 |
| CLAA150PB0B03A | LP154WU1(A1)(K2) | LP171WU3-TLA1 | LTN141WD-L07 | LTN170WX-L03 |
| HSD150PK14-A00 | LP154WU1(A1)(K3) | LP171WX2 | LTN141WD-L07 (B) | LTN170WX-L05 |
| HSD170MGW1-A00 | LP154WU1(TL)(A1) | LP171WX2(A4) | LTN150P2-L01 | LTN170WX-L08 |
| HT14P12-100 | LP154WU1(TL)(A2) | LP171WX2(A4)(K1) | LTN150P2-L03 | LTN170X2-L02 |
| HV150UX1-100 | LP154WU1(TL)(B1) | LP171WX2(A4)(K9) | LTN150P3-L01 | LTN190W1 |
| HV150UX1-101 | LP154WU2(TL)(A2) | LP171WX2(TL)(A2) | LTN150P4-L02 | N150P3-L01 |
| HV150UX1-L01 | LP171W01 | LP171WX2(TL)(A3) | LTN150PE-L01 | N150U3-L01 |
| IASX12S | LP171W01(A4) | LQ150U1LA03 | LTN150PF-L04 | N154Z1-L02 |
| IAUX14 | LP171W01(A4)(K1) | LQ150U1LH22 | LTN150PG-L02 | N170C2-L01 |
| IAUX14P | LP171WP4 | LQ150U1LW03 | LTN150PG-L03 | N170C2-L02 |
| IAUX14S | LP171WP4(TL)(02) | LQ150U1LW22 | LTN154P1-L02 | QD17TL02 |
| ITSX95C | LP171WP4(TL)(03) | LQ154M1LW02 | LTN154P1-L03 | TX41D56VC1CAA |
| ITSX95E | LP171WP4(TL)(B1) | LQ154M1LW12 | LTN154P1-L04 | TX41D97VC1GAA |
| ITUX97H | LP171WP4(TL)(B3) | LQ170M1LA04 |
PS: Not included all of model ,Other model please contact us or leave a message.
Package content:
1× New DVI+VGA Controller Board NT2261
1× New Inverter Board(1-lamp 2-lamp or 4-lamp depend on your lcd panel)
1× New LVDS Cable FIX-30P 2ch 6bit
1× Keyboard with Wire
