Computer Hot Seller Peripheral Component Parts provide Component Parts,Networking Tools,Mouse Wonderful Gift All In One pc mini Computer 12.1 inch Intel atom N2800 industrial panel pc with resistive touch screen 32G SSD affordable pc. Price at this time US $443.00/piece. Check price now to get discount! Dont waste your time. Buy Now only in Trusted Seller Store!
Mini 12.1 inch touch screen industrial panel PC support windows Os with Intel Atom N2800
industrial panel pc Advantage:
1. Fanless cooling system.
2. dual-core Intel Atom N2800 processor 1.86 GHz .
3. Built-in 802.11a/b/g/n/ac Wireless LAN+ Blue Tooth
4. 9V~30V wide range DC power input
5.2GB DDR3L Onboard RAM
6.Resistive Touch Supports Touch Function
industrial panel pc Specifications:
Model | PPC-121P344X263X55.7mm |
LED size | AUO 12.1 inch |
Display area | 245.76 x 184.32mm |
Resolution | 800*600 |
contrast | 400:1 Typ |
Scrscreen colors | 262K/16.2M 6-bit / 6-bit + FRC |
Display brightness | 350cd/m2 |
Touch panel | Touch panel of resistance |
CPU | Intel ATOM N2800 1.86Ghz |
RAM | 2GB DDR3L Onboard RAM (4Gb Max) |
storage | SSD 32Gb ( optional 64GB,128GB,256GB ) |
Audio | 1 x AMP 2W (internal speaker) Optional |
System | Windows 7 (Pre-install) Windows XP/ win7 / linux |
LAN | 2 x RJ45 Intel RTL8111E 1000Mbps |
Wireless (Optional) | IEEE 802.11a/b/g/n/ac |
IO | 1 x RS-485 COM Port 3 x RS-232 COM port 4 x USB 2.0 |
Microphone Input/output | 1 (optional) |
IP Level(front panel) | IP 65 front |
Mounting | Wall, Panel, Stand, Rack Mounting (VESA 75 mm x 75 mm) |
Operating Humidity | 5 ~ 90% (non-Condensing) |
Operating Temp | -20 ~ 60 Celsius degree |
Storage Temp | -20 ~60 Celsius degree |
Color | Silver |
Power Supply | 110V-240V AC |
12V/5A DC | |
Weight | 3.95KG/set |
Ordering Information:
Part No:
PPC-121P
Description:
12.1’’ 450 cd/m2 800x600 HD fanless panel PC with Intel Atom N 2800
dual core 1.86 GHz, Resistive touch screen, on-board 2GB DDR3L RAM
Packing List :
1 x CD Driver
1 x 60W Power Adapter ;Input: 100VAC~240VAC, 47-63Hz , 1A; Output: 12VDC
4 x Mounting Kit
MORE PICTURE:
panel pc
1.The Fanless industrial panel pc was made of brushed aluminum in beautiful shape, no cable is good at shockproof, and high performance at low power consumption, can be used in hard environments. It supports wireless 3G/WIFI for optional .
2. With the shockproof, moisture-proof, waterproof and dustproof (meet the NEMA IP65 standard), high temperature resistant, multi-solt and easy to expand characteristics, so it is widely used in industrial control,vehicle control, environmental control ,Miliary control, Monitoring system,Network security, Digital signage, Date storge and other automation applications.
3.With 12.1 inch resistive touch screen, brightness and contrast can be adjusted, and also have standby energy saving mode.It with integrated industrial-grade low-power embedded motherboard, support Windows 7 (Pre-install), Windows XP/ win7 system ,CF,HDD,SDD, multiple I/O interfaces.
NOTE: Within 18 months, if you need to ship us back the product 30 days after the day you receive it, we will provide you with a free labor and free parts, but you must cover shipping costs. And if your product becomes faulty after 18 months of purchase, you can send it back and we will repair it, free of charge. However, shipping fees and additional parts may be billed to you.
Shipping & handling policy:
1. most products can be sent within 1-3 days after you payment.
2. We will make shipment according to the address you put on AliExpress,if you want us to ship to others address please contact us before we shipment.
3. We ship to worldwide,in order to guarantee the shipping efficiency,please try to choose the registered post or express to ship the goods,the tracking number help you to hold the shipping situation.
4. If you can’t receive the package for more than 4 weeks,please contact us.
5. Products can be combined into one invoice but the total shipment cost will be the sum of each product shipping and handling charge.
6. Intemational buyer note:
A. Import duties,taxes and charges are not included in the product pirce and shipment cost.
B. Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying.
7.Please kindly leave 5 ★ DSR (detailed seller rating) good comment and positive feed back to us if you are happy with the transaction, both of them are ultimately important to us. If a defective product was received or you are unsatisfied with our products or service,please do communicate with us via email or trademager message and let’s have the opportunity to make you satisfied before you leave any non-five STARS DSR, poor feedback.
Return Policy
If the product you receive is not as described or low quality, the seller promises that you may return it before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe) and receive a full refund. The return shipping fee will be paid by you. Or, you can choose to keep the product and agree the refund amount directly with the seller.N.B.: If the seller provides the "Longer Protection" service on this product, you may ask for refund up to 15 days after order completion.
Seller Service
On-time Delivery: If you do not receive your purchase within 60 days, you can ask for a full refund before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe).Wonderful Gift All In One pc mini Computer 12.1 inch Intel atom N2800 industrial panel pc with resistive touch screen 32G SSD affordable pc
